Benefits:
For throttling control applications, one type of butterfly valve is now the industry standard: high-performance butterfly valves (HPBVs) or double offset valves. Their advantages include a straight-through flow path, very high capacity, and the ability to pass solids and viscous media.
Types:
Double Eccentric Butterfly Valve
Triple Eccentric Butterfly Valve
High-Performance Butterfly Valves
Butterfly valves are suitable for simple as well as highly complicated ones. Our Butterfly valves are high-performance duty.
Butterfly valves are suitable for both open/closed and rare utilization in controlling valves. They are obtainable in a broad category
of sizes, materials, and models. Butterfly valves can be operated with multiple controls operations like electric/pneumatic actuator
possibilities.
SPECIFICATIONS:
BODY | WCB / CF8 / CF8M / DUPLEX / ALL BRONZE |
DISC | WCB / CF8 / CF8M / DUPLEX / ALL BRONZE |
SEAT | EPDM / VITON / NBR / PFA / PTFE / RPTFE |
SHAFT | AISI 410 / AISI 304/AISI 316 |
MFG STD | API 609 / ASME B 16.34 |
INSP & TEST STD | API 598 |
OPERATION | MANUAL GEAR OPERATED / PNEUMATIC ACTUATOR / ELECTRIC ACTUATOR |
ENDS | ANSI B 16.5 #150 |
HYD TEST PRESSURE | BODY : 225 PSIG (16 KG/CM2) SEAT : 165 PSIG (11.5 KG/CM2) |
SIZE RANGE | 50 NB TO 600 NB (2″ to 24″) |
